About this ebike...
The Kathmandu Hybrid‘s Easy Entry frame is designed to do exactly what it says, making adventurous cycling as accessible and straightforward as possible. The neatly housed Bosch CX drive and 800 Wh PowerTube battery are just the start. Efficient Comfort Geometry is designed around a 100mm travel suspension fork, for better control even when the going gets rough. Integrated cables complement the frame’s clean lines and help reduce the need for maintenance, while a UDH dropout is tough, versatile and future-proof. And, of course, there’s an integrated chainguard mount and Cube’s tough, sturdy and exceptionally neat Integrated Carrier 3.0, so you can carry everything you need for your adventures.
The Kathmandu Hybrid EX 800 is also available to order in Crossbar and Trapeze designs.
Please contact Velospeed on 01635 579 304 for further details.
Trial this ebike
Fancy taking this ebike for a test ride yourself?
We think it’s important to make sure this ebike feels perfect for you so come along and have a free test ride!
TRIAL THIS EBIKE
Customise this ebike
We know that sometimes you need to adjust a bike to make it a perfect fit and feel “right”. Sometimes it’s just a tweak to the handlebars maybe. Sometimes you may want a different saddle. We will try to make your bike just right for you.
FIND OUT MOREFeatures we love
Gravity Casting Gravity Casting moulds liquid aluminium into highly complex frame sections, resulting in extremely strong structures that can better withstand stress.
Internal Cable Routing Takes the clutter of external cables and consigns it to the past.
Modular Battery System Charge the battery on or off the bike, and there's room for even high capacity batteries.
Integrated Carrier 3.0 Incredibly strong and rigid, with an integrated spring clamp and CUBE Rilink ready adaptor for mounting bags and baskets.
Boost 148 Rear Hub Wider hub for stiffer wheel and better handling. Allows wider flange spacing for better wheel performance without impacting on shifting accuracy or drivetrain efficiency.
Efficient Comfort Geometry Frame With the specially designed Efficient Comfort Geometry, cycling is a simple pleasure.
The Nitty Gritty
Range Up to 80 miles
Motor Bosch Performance Line CX 85Nm (BDU38), Smart System
Weight 29.3kg
Gears Shimano Cues RD-U6000-GS, 11-Speed
Full specification
Frame Aluminium Superlite, Gravity Casting Technology, Efficient Comfort Geometry, Boost148, Fully Integrated Battery, Integrated Carrier 3.0, Advanced Internal Cable Routing, 1.5 Headtube
Size Easy Entry: XS / 46cm, S / 50cm, M / 54cm, L / 58cm, XL / 62cm Trapeze: XS / 46cm, S / 50cm, M / 54cm, L / 58cm Classic: S / 50cm, M / 54cm, L / 58cm, XL / 62cm
Suspension Fork SR Suntour Mobie 35 EQ Air, ABS, Tapered, 15x110mm, 100mm
Motor Bosch Performance Line CX 85Nm (BDU38), Smart System
Battery Bosch Power Tube 800
Remote Bosch LED Remote
Display Bosch Kiox 300
Charger Bosch 2A
Range Up to 80 miles*
Brake System Magura MT C ABS, Hydr. Disc Brake (203/203)
Rear Derailleur Shimano Cues RD-U6000-GS, 11-Speed
Shifters Shimano Cues SL-U6000, Rapidfire-Plus
Crankset ACID MTB Hybrid Pro
Cassette Shimano Cues CS-LG400, 11-50T
Chain KMC eGlide
Headset ACROS AZF-1035, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), HIC
Stem CUBE Comfort Stem Pro, 31.8mm, Adjustable
Handlebar CUBE Comfort Trail Bar, 700mm
Grips ACID Travel Comfort
Rims CUBE EX25, 32H, Disc, Tubeless Ready
Front Hub CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt
Rear Hub CUBE Engineered By Newmen, 12mm, Boost, Centerlock
Tyres Schwalbe Big Apple, Active, 55-622
Saddle ACID Sequence Pro Plus
Seatpost CUBE Suspension Seatpost HD, 31.6mm
Pedals ACID PP MTB
Front Light ACID Front Light PRO-E 60 X-Connect, 12V, DC
Rear Light ACID Mudguard Rear Light PRO-E, 12V, DC
Kickstand ACID FM Pure Kickstand
Mudguards ACID 65 Integrated Carrier 3.0
Bell Easy Bell
Carrier ACID Integrated Carrier 3.0, CUBE Adapter Compatible
Weight Classic and Trapeze: 27.4 kg / Easy Entry: 29.3 kg
Colour electricblue´n´chrome / haze´n´black
Is this the right ebike for me?
The Kathmandu Hybrid EX 800 from CUBE has got your back, wherever you take it. Its powerful Magura MT C ABS hydraulic disc brakes feature an ABS system to prevent the front wheel from losing grip, helping to keep you safe in all weathers and even under heavy braking. The Bosch CX drive has up to 85 Nm of torque in pedal assistance to dish out, backed up by the 800 Wh PowerTube battery and delivered to the rear wheel via Shimano’s easy-to-use Cues 11-speed gears. There’s a suspension seatpost, adjustable stem and a Suntour Mobie 34 fork to keep you comfortable. The Integrated Carrier 3.0 is adaptable and sturdy enough to take care of pretty much any load-carrying, whether it’s for commuting or touring. And there’s a full complement of accessories, so you can just concentrate on the ride.
